Model :DR-PT-LC-OM3 Connector: LC/UPC Fibers: OM3 Color : connector is grey,cable is aqua Diameter: 0.9MM Insertion Loss: ≤0.3 Return Loss:≥50
Fiber optic pigtails the typical use is to link the fiber optic cable with fiber optic equipment, the fiber optic pigtail with connector side is used to link the equipment, while the other side of the pigtail is melted together with the fiber cable, by melting together the fiber glasses, it can reach a minimum insertion loss. Common types of fiber optic pigtails are usually with 0.9mm fiber cable diameter, and usually installed inside ODF unit.
Features:
Low insertion loss
High return loss
Excellent mechanical endurance
Good in repeatability and exchangeability
Application:
Telecommunications
FTTX
CATV
Optical communication system
Specification:
Fiber type
SM
9/125, G.652D, G657A
MM
50/125, 62.5/125, OM3
Connector
Type
SC, ST, LC ,FC, SC/APC, FC/APC, LC/APC
Boot Color
Blue, green , Beige...
Hood
Ø 0.9 mm, 2.0mm, 3.0mm
Materials
Ferrule
Zirconia
Boot
Beige , black , yellow, green , blue...
Dust cap
PE (white,or other)
Cable
PVC Buffer, LZSH, Aramid yarn, PVC jacket…
Length
1~2 meters
Technical Characteristics
Insertion Loss
< 0.3dB
Return Loss
SM:> 45 dB(PC) >50 (UPC), >60(APC); MM:>35 dB
Operating Temperature
-40°C to +85°C
